120W High Power Portable 8 Channels GSM 3G 4G 5G Mobile Signal Jammer
Product Description:
High Power 8 Channels Mobile Signal Jammer 200W up to 300 meters is the latest professional signal jammer of high power.
Each module with antenna can be used as a single jammer. The prison jammer is waterproof and portable, the jammer case is our patent design, it can be installed in desert and more rain of bad weather. The Frequency band is optional. And the high power jammer is with excellent heat dispersion.
Features:
1,Large coverage, covering CDMA,GSM,PCS,DCS,3G,4G LTE,4G Wimax,GPS,WIFI...etc.
2,Draw-bar box designed for portability and easy moving;
3,Built-in rechargeable battery can be used for 90~120 minutes after being fully charged;
4,Military standard casing, which is anti-throw, pressure-resistant and durable;
5,AC110-220V/Built-in battery supply (DC24V);
6,Built-in efficient cooling fan and cooling fans ensures the product work stably in a long service life;
Specification:
Affected Frequency Ranges: (12 bands option)
We could supply customized service by your detail requirements about frequencies setting. All 4-12 Frequency modules we can mix very flexibly.
| Output Interface | Output Frequency |
| CH1 | CDMA: 851-960MHz /-GSM: 925-960MHz |
| CH2 | DCS: 1805-1880MHz |
| CH3 | PCS: 192-1990MHz |
| CH4 | 3G: 2110-2170MHz |
| CH5 | 4G Wimax: 2300-2400MHz(US) or 2620-2690MHz(EU) |
| CH6 | 4G LTE: 725-770MHz(US) or 790-826MHz(EU) |
| CH7 | GPS: 1500-1600MHz |
| CH8 | WiFi: 2400-2500MHz |
| Jammed Signal Freqency: | CDMA,GSM,PCS,DCS,3G,4G LTE,4G Wimax,GPS,WIFI |
| Type: | Portable jammer |
| Jammer Module Number | 8 |
| Total output power | 200W |
| Transmission Power: | Integrated Equipment≥200W,each channel≥25W |
| Parameter Shielding Range: | Radius 100-300 meters(-75dBm,depending on the distance of base station in an open filed) |
| HS Code: | 8543709200 |
| Packing: | Box |
| Weight | 35kg |
| Dimension (not including antennae): | 556*455*266cm (Protrusions excluded) |
| Material: | Pelican case |
| Technical Parameters: |
| Power supply | 50 to 60Hz, 100 to 240V AC |
| External double channel directional panel antennas | all the TX frequency covered down link only |
| With AC adapter | (AC100-240V-DC27V) |
| Design | Customized Jammer |
| Humidity: | ≤80% |
| Ambient Temperature | -10ºC - +50ºC |
| Power Consumption | ≤360W |
| Battery | 24V,33AH,Built-in standby battery can used for 90~120 minutes |
| Antenna Parameters | Omni antennas,gain:4~5dBi |
| Switch Control | Manually |
Products Application Fields
High quality jammers widely use in Military Units, Prison, Police, Bomb Disposal and Security Services.
It can also be used in places like Prison, Gas Stations, Guard, Schools, Churches, Invigilate Meeting Room, Library, Hospitals, Theater, Class Room and other important places and situations.
| Terms and conditions: |
| Delivery Time Schedule | Delivery time is 3 weeks, Delivery will be initiated from date of receipt of confirmed purchase order and advance remittance in our bank. |
| Payment Terms | 50% advance, 50% before shipping. |
| Terms of Delivery | FOB HONGKONG/ USA. |
| Warranty | 36 months. |
| Software Updates | Free software updates will be provided for a period of 36 months. |
| Extended Warranty | After 4th Year :5% of total for each years. |
Product Tags:
|
|
120W High Power Portable 8 Channels GSM 3G 4G 5G Mobile Signal Jammer Images
|
